Details & Specifications
Everything technical about this product: specifications, what's in the box and downloads.
Downloads
General 6
| Brand | Rode |
|---|---|
| Product type | Shotgun Microphone |
| Features | Low-Cut filter |
| Microphone design | Condenser |
| Polar pattern | Supercardioid |
| Power source | 48V phantom power |
Audio 5
| Max SPL | 130 dB SPL |
|---|---|
| Signal-to-noise ratio | 81 dB A-Weighted |
| Self noise | 13 dB-A |
| Diaphragm size | 12.70 mm |
| Mono / stereo | Mono |
Connectivity 3
| Connectivity | XLR |
|---|---|
| Connection type | XLR |
| Microphone thread | 5/8"-27 |
Dimensions & weight 2
| Dimensions | 25.5 x 1.9 x 1.9 cm |
|---|---|
| Weight | 163g |
In the box
Features
Warranty 1
| Warranty | 3-Year |
|---|
Sources: Manufacturer data
Compare
Rode NTG3From €599,00 | sE Electronics sE6160€549,00 | sE Electronics sE6160 (Matched Pair)€1.099,00 | Sennheiser MKE 600€299,00 | |
|---|---|---|---|---|
| General | ||||
Product type |
Shotgun Microphone
|
Shotgun Microphone
|
Shotgun Microphone
|
Shotgun Microphone
|
Price |
€599,00 |
€549,00 |
€1.099,00 |
€299,00 |
Barcode |
698813002962
|
819032012406
|
819032012413
|
4044155074871
|
Brand |
Rode
|
SE Electronics
|
SE Electronics
|
Sennheiser
|
Rating |
|
|
|
|
Warranty |
3-Year
|
3-Year
|
3-Year
|
3-Year
|
Availability |
|
—
|
—
|
—
|
PDF Manual | ||||
| Specifications | ||||
Color |
BlackSilver |
Black |
Black |
Black |
Connectivity technology |
XLR
|
Wired
|
Wired
|
Wired
|
Connection type |
XLR
|
XLR
|
XLR
|
XLR
|
Power source |
48V phantom power
|
48V phantom power
|
48V phantom power
|
48V phantom power and Batteries
|
Features |
Low-Cut filter
|
Low-Cut filter and Pad
|
Low-Cut filter and Pad
|
Low-Cut filter
|
Dimensions |
|
|
|
|
Weight |
|
|
—
|
|
Microphone thread Thread size on the stand or mount: 3/8 inch (European standard) or 5/8 inch (US, used by most mic clips). Adapters between the two are inexpensive.
|
5/8"-27
|
5/8"-27
|
5/8"-27
|
5/8"-27
|
Polar pattern Directions from which the microphone picks up sound. Cardioid rejects sound from behind (vocals, streaming); omnidirectional picks up evenly all around; figure-8 from front and back; supercardioid is tighter than cardioid.
|
Supercardioid
|
Supercardioid
|
Supercardioid
|
Supercardioid
|
Microphone design Capsule technology. Condenser: detailed and sensitive, needs phantom power; dynamic: robust, handles loud sources, rejects room noise; ribbon: smooth vintage tone; USB: plugs straight into a computer.
|
Condenser
|
Condenser
|
Condenser
|
Condenser
|
Max SPL Loudest sound level the microphone handles before distorting, in dB SPL. Above about 130 dB it copes with drums, guitar amps and brass without a pad.
|
|
—
|
—
|
—
|
Signal-to-noise ratio Difference between the signal level and the microphone's own noise, in dB. Higher is cleaner; 80 dB or more is excellent.
|
|
—
|
—
|
—
|
Diaphragm size Size of the capsule diaphragm. Large diaphragms (about 1 inch) sound fuller with lower noise; small diaphragms are more accurate and consistent off-axis.
|
|
—
|
—
|
—
|
Self noise Noise the microphone itself adds, in dB(A). Lower is better; under about 15 dB(A) is very quiet and suits soft sources and distant miking.
|
|
—
|
—
|
—
|
